DJI Matrice 350 RTK Drone, Without Batteries

Description

• Aircraft Body – RC Plus Remote Controller – 2x Landing Gear – 2110s Propeller (Pair) – WB37 Intelligent Battery for Controller – 4x Spare Gimbal Damper – Cleaning Tools – Rubberport Cover (Set) – Carrying Case – Screws and Tools – User Manual – (Batteries Not Included) – DJI 1 Year Limited Warranty
• Discover unparalleled precision with the Matrice 350 RTK’s advanced RTK module, ensuring centimeter-level accuracy for surveying, mapping, and inspection needs
• Elevate your flying experience with the Matrice 350 RTK’s six-directional obstacle avoidance system, providing enhanced safety and security during every flight
• Embark on extensive missions with confidence, thanks to the Matrice 350 RTK’s remarkable flight time of up to 55 minutes, perfect for long-range endeavors
• Unleash your creativity with the Matrice 350 RTK’s adaptable payload compatibility, empowering you to equip cameras, sensors, and LiDAR for a vast array of applications
• Dimensions (unfolded, without propellers)
  Length 810 mm, width 670 mm, height 430 mm
  Dimensions (folded, with propellers)
  Length 430 mm, width 420 mm, height 430 mm
  Symmetrical motor wheelbase
  895 mm
  Weight (with single gimbal bracket at bottom)
  Empty weight (without batteries):
  Approximately 3.77 kg
  Empty weight (with dual batteries):
  Approximately 6.47 kg
  Maximum load of single gimbal shock absorber ball
  960 g
  Maximum takeoff weight
  9.2 kg
  Operating frequency
  2.4000 GHz to 2.4835 GHz
  5.150 GHz to 5.250 GHz (CE: 5.170 GHz to 5.250 GHz)
  5.725 GHz to 5.850 GHz
  Not supported in some regions The 5.1 GHz and 5.8 GHz frequency bands, as well as the 5.1 GHz frequency band in some areas, are limited to indoor use. Please refer to local laws and regulations for details.
  Transmit power (EIRP)
  2.4000 GHz to 2.4835 GHz:
  <33 dBm (FCC)
  <20 dBm (CE/SRRC/MIC)
  5.150 GHz to 5.250 GHz (CE: 5.170 GHz to 5.250 GHz):
  <23 dBm (CE)
  5.725 GHz to 5.850 GHz:
  <33 dBm (FCC/SRRC)
  <14 dBm (CE)
  Stay-in-air accuracy (windless or light wind environment)
  Vertical:
  ±0.1 meter (when visual positioning is working properly)
  ±0.5 meter (when GNSS is working properly)
  ±0.1 meter (when RTK positioning is working properly)
  Horizontal:
  ±0.3 meter (when visual positioning is working properly)
  ±1.5 meter (GNSS Normal operation)
  ±0.1 m (RTK positioning is operating normally)
  RTK position accuracy (at RTK FIX)
  1 cm + 1 ppm (horizontal)
  1.5 cm + 1 ppm (vertical)
  Maximum rotation angular velocity
  Pitch axis: 300°/sec
  Yaw axis: 100°/sec
  Maximum pitch angle
  30°
  25° when using N mode and forward vision system is enabled.
  Maximum ascent speed
  6 m/sec
  Maximum descent speed (vertical)
  5 m/sec
  Maximum tilt descent speed
  7 m/sec
  Maximum horizontal flight speed
  23 m/sec
  Maximum flight altitude
  5000 m
  When using 2110s propellers and takeoff weight does not exceed 7.4 kg.

  7000 m
  When using 2112 high altitude silent propellers and takeoff weight does not exceed 7.2 kg.
  Maximum wind speed
  12 m/s (force 7 wind)
  Maximum flight time
  55 minutes
  Measured in a windless environment and without a load, flying forward at about 8 m/s until the battery is exhausted. For reference only. The actual usage time may vary due to different flight methods, accessories and environments. Please pay attention to the app prompts.
  Applicable DJI gimbals
  Zenmuse H30, Zenmuse H30T, Zenmuse H20, Zenmuse H20T, Zenmuse H20N, Zenmuse L2, Zenmuse L1, Zenmuse P1, Zenmuse S1, Zenmuse V1
  Third-party payloads
  Only certified payloads developed based on DJI Payload SDK are supported.
  Supported gimbal installation methods
  Single gimbal at bottom
  Single gimbal at top
  Dual gimbal at bottom
  Single gimbal at bottom + single gimbal at top
  Dual gimbal at bottom + single gimbal at top
  IP protection level
  IP55
  The protection level is not a permanent standard and the protection capability may decrease due to product wear.
  GNSS
  GPS + GLONASS + BeiDou + Galileo
  Operating temperature
  -20°C to 50°C
  Classification
  EU C3
  Remote control
  Display
  7.02-inch touch-screen LCD display, resolution 1920×1200, maximum brightness 1200 nits
  Weight
  Approximately 1.25 kg (without WB37 battery)
  Approximately 1.42 kg (with WB37 battery)
  GNSS
  GPS + Galileo + BeiDou
  Built-in battery
  Type: Li-ion (6500 mAh @ 7.2 V)
  Charging method: Use a battery box or a USB-C fast charger with a maximum power of 65 watts (maximum voltage 20 volts)
  Charging time: 2 hours
  Chemistry system: lithium nickel cobalt aluminum oxide
  External battery (WB37 smart battery)
  Capacity: 4920 mAh
  Voltage: 7.6 Volts
  Type: Li-ion
  Energy: 37.39 watt-hours
  Chemistry: Lithium cobalt oxide
  IP rating
  IP54
  Battery life
  Internal battery: about 3.3 hours
  Internal battery + external battery: about 6 hours
  Operating temperature
  -20℃ to 50℃
  Operating frequency
  2.4000 GHz to 2.4835 GHz
  5.725 GHz to 5.850 GHz
  Transmit power (EIRP)
  2.4000 GHz to 2.4835 GHz:
  <33 dBm (FCC)
  <20 dBm (CE/SRRC/MIC)

  5.725 GHz to 5.850 GHz:
  <33 dBm (FCC)
  <14 dBm (CE)
  <23 dBm (SRRC)
  Wi-Fi protocol
  Wi-Fi 6
  Wi-Fi Operating frequency band
  2.4000 GHz to 2.4835 GHz
  5.150 GHz to 5.250 GHz
  5.725 GHz to 5.850 GHz
  Bluetooth protocol
  Bluetooth 5.1
  Bluetooth operating frequency band
  2.4000 GHz to 2.4835 GHz
  Image transmission
  Image transmission solution
  DJI O3 Image Transmission Industry Edition
  Antenna
  Four image transmission antennas, two transmit and four receive
  Maximum signal effective distance (no interference, no shielding)
  20 km (FCC)
  8 km (CE/SRRC/MIC)
  Maximum signal effective distance (with interference)
  Weak interference and building obstruction: about 0 km to 0.5 km
  Weak interference and tree obstruction: about 0.5 km to 3 km
  Strong interference and no obstruction: urban center, about 1.5 km to 3 km km
  Moderate interference without obstruction: suburban/urban areas, about 3 km to 9 km
  Strong interference without obstruction: remote suburbs/seaside, about 9 km to 20 km
  The above data is measured at an altitude of about 120 meters in various unobstructed and typical interference environments using FCC standards. It is for reference only. The actual data may vary due to the obstruction and interference conditions of the environment. Please pay attention to the application prompts.
  Visual sensing system
  Obstacle sensing range
  Front, back, left, and right: 0.7m to 40m
  Up and down: 0.6m to 30m
  Field of view (FOV)
  Front, back, and down: 65° (horizontal), 50° (vertical)
  Up and down: 75° (horizontal), 60° (vertical)
  Usage environment
  The surface has rich textures and the lighting conditions are sufficient (>15 lux, normal indoor fluorescent lighting environment)
  Infrared sensing system
  Obstacle sensing range
  0.1m to 8m
  Field of view (FOV)
  30° (±15°)
  Usage environment
  Diffuse reflection, large size, high reflectivity (reflectivity exceeds 10%)
  LED fill light
  Effective lighting distance
  5m
  Lighting method
  60 Hz, always on
  Flight camera
  Resolution
  1080p
  Field of view (FOV)
  142°
  Frame rate
  30fps
  Smart flight battery
  Model
  TB65
  Capacity
  5880 mAh
  Voltage
  44.76 V
  Battery type
  Li-ion
  Energy
  263.2 Wh
  Weight
  Approximately 1.35 kg
  Operating temperature
  -20°C to 50°C
  Ideal storage temperature
  22°C to 30°C
  Charging temperature
  -20°C to 40°C
  When the ambient temperature is below 5°C, the battery will start the self-heating function. Charging in a low temperature environment may shorten the battery life. It is recommended to charge in an environment of 15°C to 35°C.
  Charging time
  When using a 220-volt power source, it takes about 60 minutes to fully charge two TB65 Intelligent Flight Batteries, and about 30 minutes to charge from 20% to 90%.
  When using a 110-volt power source, it takes about 70 minutes to fully charge two TB65 Intelligent Flight Batteries, and about 40 minutes to charge from 20% to 90%.
  Smart Battery Box
  Dimensions
  Length 580 mm, width 358 mm, height 254 mm
  Empty Box Weight
  Approximately 8.98 kg
  Storable Items
  8 TB65 Smart Flight Batteries
  4 WB37 Smart Batteries
  Input Voltage
  100 VAC to 120 VAC, 50 Hz to 60 Hz
  220 VAC to 240 VAC, 50 Hz to 60 Hz
  Maximum Input Power
  1070 W
  Output Power
  100 V to 120 V: 750 W
  220 V to 240 V: 992 W
  Operating Temperature
  -20°C to 40°C
